    4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter

    Ask Lasest Price
    Brand Name : XUWEN
    Model Number : 4S-24S Lithium BMS System
    Certification : CE,FCC,RoHS,UN38.3,MSDS
    Price : To be negotiated
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 100000pcs/month
    Delivery Time : To be negotiated
    • Product Details
    • Company Profile

    4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter

    100a 120a 150a 160a 4S-24S Lithium BMS System High Current Lifepo4 Pcm/Pcb Board For E-Scooter


    ModelLWS-24S160A-445(24S) lifepo4
    Test No.Test itemDetailsCriterion
    1VoltageCharging voltageDC:86.4v CC/CV
    Balance voltage for single cell3.650±0.025V
    2Current

    Balance current for single cell

    Current consumption

    72±10mA

    ≤20μA

    Maximal continuous charging current100A
    Maximal continuous Discharging current100A
    3Over charge ProtectionOver charge detection voltage for single cell3.90±0.025V
    Over charge detection delay time0.5S—2S
    Over charge release voltage for single cell3.80±0.025V
    4Over discharge protectionOver discharge detection voltage for single cell2.00±0.05V
    Over discharge detection delay time10mS—200mS
    Over discharge release voltage for single cell2.30±0.05V
    5Over current protectionOver current detection voltage0.62V
    Over current detection current600±100A
    Detection delay time5ms—20ms
    Release conditionCut load
    6Short protectionDetection conditionExterior short circuit
    Detection delay time200-500us
    Release conditionCut load
    ResistanceProtection circuitry(MOSFET)≤50mΩ
    7TemperatureOperating Temperature Range-40~+85℃
    Storage Temperature Range-40~+125℃

    4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter4S-24S Lithium BMS System 150a 160a Multi layer For E Scooter
