Lifepo4 BMS PCM Battery Protection Board 16S 25A 45A FR4 Material

Product Categories

Shenzhen XUWEN Technology Co.,Ltd

Contact Now

Name: Lifepo4 BMS PCM Battery Protection Board 16S 25A 45A FR4 Material
Brand: XUWEN
Price: 1 USD

Ask Lasest Price
Brand Name :	XUWEN
Model Number :	16S 25A 45A Hardware BMS Battery Management System
Certification :	ISO9001/Iso14001/CE/ROHS
Price :	To be negotiated
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	100000pcs/month
Delivery Time :	To be negotiated

Add to Cart

16S 25A 45A Hardware BMS Battery Management System Lifepo4 Battery Bms UPS 48v 60 battery management system

3.2V BMS Main Parameters
Charging Volt	3.65*Series	Discharge current same as bms	Charge Current	Depends on parameters
Overcharge protection	3.65V+0.025V	Detection Delay: 1000+500ms	Release Volt	3.55V+0.05V
Overdischarge Protection	2.35+0.1V	Detection Delay: 1000+500ms	Release Volt	2.7+0.1V
Balance Function	3.5V+0.025V	Detection Delay: 100+50ms	Balance Current	36+5MA
Over current Protection	50+15MV	Detection Delay: 1000+500ms	Current Protection	300+50A,450+50A,600+60A
Short Circuit Protection	YES	Detection Delay: 300US	off load
Temperature protection	Charging Temp: 55 degree	Discharging Temp:75 degree	Recover while temperature reach normal charging temp
Self Consumption	Working :35uA	Rest :<10uA	Working Temp	-30 to 80 degree

3.7V BMS Main Parameters
Charging Volt	Series*4.25V	Discharge Current :Same as bms current	Charge current	:Depends on specification
Overcharge protection	4.25+0.025V	Detection Delay: 1000+500ms	Release Volt	4.15+0.05V
Overdischarge protection	2.75+0.1V	Detection Delay: 1000+500ms	Release Volt	3+0.1V
Balance Function	4.15+0.025V	Detection Delay: 100+50ms	Balance Current	42+5MA
Overcurrent Protection	50+15mv	Detection Delay: 1000+500ms	Current protection	300+50A 450+50A 600+60A
Short circuit protection	YES	Detection delay	300us	Off load
Temperature Protection	Charging temp: 55 degree	Discharging temp 75degree	Release method	Temperature recover to normal charging temp
Self consumption	Working <35ua	Rest <10ua	Working Temp	-30 to 80 degree
